Item is fairly worn but still functional. Significant signs of cosmetic damage can include scratches, dents, and worn corners. Item may arrive with damaged packaging or be repackaged. Item may be missing parts, accessories, or instruction manuals.
All items are final sales while supplies last.
Not Eligible for Refunds or Exchanges.
DETAILS
24 HOUR WITH SKIP 14 DAY
MAXIMUM NUMBER OF OPERATIONS 60
MINIMUM ON TIME 12 MIN
MINIMUM OFF TIME 12 MIN
DPST SWITCH
25 AMPERE
120 V AT 60 HZ
POWER RATING 1-1/2 HP
RESERVE POWER NO
NEMA 3R
PLASTIC
WALLSpecs
Input Voltage Range(s)120 VAC, 60 Hz
MaximumOnOffOperations44
Mechanism TypeAnalog/MechanicalS
witch TypeDPST
Enclosure TypeIndoor/outdoor type 3R plastic
Minimum ON/OFF Times12 min
Maximum ON/OFF Times20 hours, 45 minutes
Warranty Period1-Year limited
Amps Per Pole30 A
Clock Motor Voltage125 VAC, 60 Hz
Country Of OriginMexico
HP1 1/2
Knockout Dimensions Back(1) combination 1/2″ – 3/4″
Knockout Dimensions Bottom(2) combination 1/2″ – 3/4″
Load Voltage120 VAC, 60 Hz
Motor Load Ratings (Ranges)1 1/2 HP, 120 VAC, 60 Hz
Number of Trippers Included12
Tripper Actuating Time12 min
Operating Temperature Max (°C)54
Operating Temperature Max (°F)130
Operating Temperature Min (°C)-40
Operating Temperature Min (°F)-40
Dimension
Product Depth (in)4
Product Depth (mm)101.6
Product Height (in)10
Product Height (mm)254
Product Width (in)6.5
Product Width (mm)165.1
Unit Carton Height (in)4.251
Unit Carton Length (in)11.751
Unit Carton Weight (lb)0
Unit Carton Width (in)7.251
