RANSBURG A12289-00 Valve Manifold Assembly

RANSBURG A12289-00 VALVE MANIFOLD ASSEMBLY, RMA-303 DUAL PURGE

Valve Manifold Assembly Part List

1. A12286-00 Valve Manifold, RMA-303, Dual Purge 1
2. 77367-00 Seat, Valve (See Note 1 and 2) 5
3. 78949-00 Assembly, Valve (See Note 1 and 2) 5
4. 79001-38 O-Ring, Solvent Proof (See Note 2) 5

Note 1 Apply a thin film of A11545 Petroleum jelly to O-rings before assembly
Note 2 Torque seat assembly and valve assembly after valve is down to 15-20 lbs•in
(1.69-2.26 Nm)
