- 2-5/8″ total projection from wall to face of door (3-5/8″ if using complimentary 1″ extension)
- Tri-voltage units for easy stocking and installation 12V DC, 24V AC/DC OR 120V AC
- Provided with one complimentary 1″ extension – No charge
- Optional extension rods fill the gap between the magnet and door armature with no special adapter piece required
- 35 lb. holding force
- All metal components – No plastic parts
- UL/ULC listed for smoke barrior or labeled fire doors
- Listed by the California State Fire Marshall
- Outlet box required (not provided)
- Armature features two pivot points which each have 360° mobility to help door alignment and reduce installation time
- Positive release button alleviates residual magnetism
- Average with per unit = 2.5 lbs.
CUT SHEETS
- 2100 Recessed Wall Mount Mag
- Electromagnetic Door Holder with Timer
- 2100-2300 Recessed Wall Mount Electromagnetic Holder Cut Sheet
